Numar parametru	Semnificatie	Domeniu setare	Increment minim setare	Setarea din fabrica	Setarea adoptata in aplicatia curenta	Comentariu
P0	Torque boost	0 to 30%	0.1%	6%/4%	4.0	Majorare cuplu pornire (Fortare caracteristica V/f)
P1	Maximum frequency	0 to 120Hz	0.01Hz	120Hz	120.0Hz	Frecventa maxima
P2	Minimum frequency	0 to 120Hz	0.01Hz	0Hz	0.00Hz	Frecventa minima
P3	Base frequency	0 to 400Hz	0.01Hz	50Hz	50.00Hz	Caracteristica V/f (frecventa de baza)
P4	Multi-speed setting (high-speed)	0 to 400Hz	0.01Hz	50Hz	50.00Hz	Treapta fixa viteza (viteza mare)
P5	Multi-speed setting (middle-speed)	0 to 400Hz	0.01Hz	30Hz	30.00Hz	Treapta fixa viteza (viteza medie)
P6	Multi-speed setting (low-speed)	0 to 400Hz	0.01Hz	10Hz	10.00Hz	Treapta fixa viteza (viteza mica)
P7	Acceleration time	0...3600sec/0...360sec	0.1sec/0.01sec	5sec/10sec	15.0	Dutata accelerare
P8	Deceleration time	0...3600sec/0...360sec	0.1sec/0.01sec	5sec/10sec	15.0	Durata decelerare
P9	Electronic thermal O/L relay	0 to 500A	0.01A	Rated output current	20.00A	Curentul de protectie electronica la suprasarcina

Numar parametru	Semnificatie	Domeniu setare	Increment minim setare	Setarea din fabrica	Setarea adoptata in aplicatia curenta	Comentariu
P10	DC injection brake operation frequency	0 to 120Hz	0.01Hz	3Hz	3.00Hz	Franare prin injectie de DC - frecventa de injectie
P11	DC injection brake operation time	0 to 10 s	0.1 s	0.5 s	0.5	Franare prin injectie de DC - timpul de injectie
P12	DC injection brake voltage	0 to 30%	0.1%	6%	6.0	Franare prin injectie de DC - tensiunea de injectie
P13	Starting frequency	0 to 60Hz	0.01Hz	0.5Hz	0.50Hz	Frecventa de start
P14	Load pattern selection	0 to 3	1	0	1	Selectare caracteristica sarcina
P15	Jog frequency	0 to 400Hz	0.01Hz	5Hz	5.00Hz	Frecventa de jog
P16	Jog acceleration/deceleration time	0 to 3600 s/ 0 to 360 s	0.1s/0.01s	0.5s	0.5	Timpul de accelerare / decelerare jog
P18	High-speed maximum frequency	120 to 400Hz	0.1Hz	120Hz	120.0Hz	Frecventa maxima la viteza mare
P19	Base frequency voltage	0 to 1000V,8888,9999	0.1V	9999	380.0V	Caracteristica V/f (tensiunea de baza)
P20	Acceleration/deceleration reference frequency	1 to 400Hz	0.01Hz	50Hz	50.00Hz	Frecventa de referinta pentru timpii de accelerare / decelerare
P21	Acceleration/deceleration time increments	0, 1	1	0	0	Incremente pentru timpii de accelerare / decelerare
P22	Stall prevention operation level	0 to 200%	0.1%	150%	150.0	Nivel operare pentru prevenirea blocarii motorului
P23	Stall prevention operation level compensation factor at double speed	0 to 200% , 9999	0.1%	9999	9999	Nivel operare pentru prevenirea blocarii motorului la frecventa dubla (factorul de compensare)
P24	Multi-speed setting (speed 4)	0 to 400Hz,9999	0.01Hz	9999	9999Hz	Treapta fixa de viteza (viteza 4)
P25	Multi-speed setting (speed 5)	0 to 400Hz,9999	0.01Hz	9999	9999Hz	Treapta fixa de viteza (viteza 5)
P26	Multi-speed setting (speed 6)	0 to 400Hz,9999	0.01Hz	9999	9999Hz	Treapta fixa de viteza (viteza 6)
P27	Multi-speed setting (speed 7)	0 to 400Hz,9999	0.01Hz	9999	9999Hz	Treapta fixa de viteza (viteza 7)
P29	Acceleration/deceleration pattern	0, 1, 2	1	0	0	Selectare tip caracteristica de accelerare / decelerare
P30	Regenerative function selection	0, 1	1	0	0	Selectare dispozitiv franare regenerativa
P31	Frequency jump 1A	0 to 400Hz,9999	0.01Hz	9999	9999Hz	Salt frecventa 1A
P32	Frequency jump 1B	0 to 400Hz,9999	0.01Hz	9999	9999Hz	Salt frecventa 1B
P33	Frequency jump 2A	0 to 400Hz,9999	0.01Hz	9999	9999Hz	Salt frecventa 2A
P34	Frequency jump 2B	0 to 400Hz,9999	0.01Hz	9999	9999Hz	Salt frecventa 2B
P35	Frequency jump 3A	0 to 400Hz,9999	0.01Hz	9999	9999Hz	Salt frecventa 3A
P36	Frequency jump 3B	0 to 400Hz,9999	0.01Hz	9999	9999Hz	Salt frecventa 3B
P37	Speed display	0, 0.01 to 9998	0.001 r/min	0	0.000
P38	Frequency at 5V (10V) input	1 to 400Hz	0.01Hz	50Hz	50.00Hz
P39	Frequency at 20mA input	1 to 400Hz	0.01Hz	50Hz	50.00Hz

Numar parametru	Semnificatie	Domeniu setare	Increment minim setare	Setarea din fabrica	Setarea adoptata in aplicatia curenta	Comentariu
P41	Up-to-frequency sensitivity	0...100%	0.1%	10%	10.0	Domeniul semnalizare atingre frecventa prescrisa (iesire SU)
P42	Output frequency detection	0...400Hz	0.01Hz	6Hz	6.00Hz	Pragul de comparare pentru frecventa de iesire (Iesire FU)
P43	Output frequency detection for reverse rotation	0...400Hz,9999	0.01Hz	9999	9999Hz	Pragul de comparare pentru frecventa de iesire la rotirea in sens invers

Numar parametru	Semnificatie	Domeniu setare	Increment minim setare	Setarea din fabrica	Setarea adoptata in aplicatia curenta	Comentariu
P44	Second acceleration/deceleration time	0...3600s/0...360s	0.1 s/0.01 s	5 s/10 s	10.0	Setul de 2 parametri - durata accelerare / decelerare
P45	Second deceleration time	0...3600s/0...360s, 9999	0.1 s/0.01 s	9999	9999	Setul de 2 parametri - durata decelerare
P46	Second torque boost	0 to 30%, 9999	0.1%	9999	9999	Setul de 2 parametri - majorare cuplu pornire
P47	Second V/F (base frequency)	0 to 400Hz, 9999	0.01Hz	9999	9999Hz	Setul de 2 parametri - caracteristica V/f (frecventa de baza)
P48	Second electronic thermal O/L relay	0 to 500A, 9999	0.01A	9999	9999A	Setul de 2 parametri - limitarea de curent

Numar parametru	Semnificatie	Domeniu setare	Increment minim setare	Setarea din fabrica	Setarea adoptata in aplicatia curenta	Comentariu
P52	Control panel/PU main display data selection	0,23,100	1	0	0	Selectare marime afisata pe prima pozitie (DU/PU)
P55	Frequency monitoring reference	0 to 400Hz	0.01Hz	50Hz	50,00Hz	Referinta monitorizare frecventa
P56	Current monitoring reference	0 to 500A	0.01A	Rated output current	17.00A	Referinta monitorizare curent

Numar parametru	Semnificatie	Domeniu setare	Increment minim setare	Setarea din fabrica	Setarea adoptata in aplicatia curenta	Comentariu
P57	Restart coasting time	0 to 5 s, 9999	0.1 s	9999	5.0	Intarziere la sincronizarea cu motorul in miscare la reaparitia tensiunii
P58	Restart cushion time	0 to 60 s	0.1 s	1.0 s	1.0	Durata amortizarii repornirii motorului in miscare

Numar parametru	Semnificatie	Domeniu setare	Increment minim setare	Setarea din fabrica	Setarea adoptata in aplicatia curenta	Comentariu
P59	Remote setting function selection	0, 1, 2	1	0	0	Validare comanda de la distanta (modul de comanda remote)

Numar parametru	Semnificatie	Domeniu setare	Increment minim setare	Setarea din fabrica	Setarea adoptata in aplicatia curenta	Comentariu
P60	Shortest acceleration/deceleration mode	0, 1, 2, 11, 12	1	0	0	Selectie mod control "Energy saving"
P65	Retry selection	0, 1, 2, 3	1	0	0	Validare reincercare automata (autoresetare) la activarea de alarme
P66	Stall prevention operation level reduction starting frequency	0 to 400Hz	0.01Hz	50Hz	50.00Hz	Frecventa de inceput reducere nivel limitare curent in domeniul frecventelor ridicate
P67	Number of retries at alarm occurrence	0 to 10, 101 to 110	1	0	0	Numarul de autoresetari la activarea de alarme
P68	Retry waiting time	0.1 to 360 s	0.1 s	1s	1.0	Timpul de asteptare pentru autoresetare (reincercare)
P69	Retry count display erasure	0	1	0	0	Stergere numar reincercari
P71	Applied motor	0, 1, 3, 5, 13, 15, 16, 23, 100, 101,103, 105, 106, 113, 115, 116,123	1	0	0	Selectarea tipului de motor utilizat
P72	PWM frequency selection	0 to 15	1	1	1	Selectare frecventa PWM
P73	0-5V/0-10V selection	0, 1, 10, 11	1	0	0	Setare suprapunere intrari analogice de prescriere (valoare fixa, rata fixa)
P74	Filter time constant	0 to 8	1	1	1	Constanta de filtrare intrari analogice
P75	Reset selection/disconnected PU detection/PU stop selection	0 to 3, 14 to 17	1	14	14	Setare functie tasta Stop/Reset
P77	Parameter write disable selection	0, 1, 2	1	0	0	Validare scriere parametri
P78	Reverse rotation prevention selection	0, 1, 2	1	0	0	Setare prevenire rotire in sens invers
P79	Operation mode selection	0 to 4,6 to 8	1	0	0	Selectare mod operare

Numar parametru	Semnificatie	Domeniu setare	Increment minim setare	Setarea din fabrica	Setarea adoptata in aplicatia curenta	Comentariu
P80	Motor capacity	0.2 to 7.5kW, 9999	0.01kW	9999	9999	Putere motor (pentru modul de control vectorial)
P96	Auto-tuning setting/status	0, 1	1	0	0	Starea setarii de optimizare automata

Numar parametru	Semnificatie	Domeniu setare	Increment minim setare	Setarea din fabrica	Setarea adoptata in aplicatia curenta	Comentariu
P117	Station number	0 to 31	1	0	0	Interfata panou operare - numar statie
P118	Communication speed	48, 96, 192	1	192	192	Interfata panou operare - rata transfer
P119	Stop bit length	0, 1 , 100,101 (data length 8) 10, 11, 110, 111 (data length 7)	1	1	1	Interfata panou operare - biti stop
P120	Parity check presence/absence	0, 1, 2	1	2	2	Interfata panou operare - paritate
P121	Number of communication retries	0 to 10,9999	1	1	1	Interfata panou operare - numar reincercari
P122	Communication check time interval	0, 0.1 to 999.8 s, 9999	0.1 s	9999	9999	Interfata panou operare - intervalul de timp pentru verificare
P123	Waiting time setting	0 to 150, 9999	1	9999	9999	Interfata panou operare - Setare timp asteptare
P124	CR�LF presence/absence selection	0, 1, 2	1	1	1	Interfata panou operare - Caracter terminator CR/LF

Numar parametru	Semnificatie	Domeniu setare	Increment minim setare	Setarea din fabrica	Setarea adoptata in aplicatia curenta	Comentariu
P128	PID action selection	0, 20, 21	1	0	20	Selectie actiune PID
P129	PID proportional band	0.1 to 1000%, 9999	0.1%	100%	100.0	PID - Banda de proportionalitate
P130	PID integral time	0.1 to 3600 s, 9999	0.1 s	1 s	2.0	PID - Timpul de integrare
P131	Upper limit	0 to 100%, 9999	0.1%	9999	9999	PID - Limita superioara
P132	Lower limit	0 to 100%, 9999	0.1%	9999	9999	PID - Limita inferioara
P133	PID action set point for PU operation	0 to 100%	0.01%	0%	0.00	PID - Valoarea prescrisa
P134	PID differential time	0.01 to 10.00 s, 9999	0.01 s	9999	9999	PID - Timpul de derivare

Numar parametru	Semnificatie	Domeniu setare	Increment minim setare	Setarea din fabrica	Setarea adoptata in aplicatia curenta	Comentariu
P145	Parameter for option (FR-PU04).	0 la 7	1	1	1	Selectare limba panou operare PU
P146	Parameter set by manufacturer. Do not set.	-	-	1	1	Parametru setat de producator. Nu setati.

Numar parametru	Semnificatie	Domeniu setare	Increment minim setare	Setarea din fabrica	Setarea adoptata in aplicatia curenta	Comentariu
P150	Output current detection level	0 to 200%	0.1%	150%	150.0	Prag detectie curent iesire
P151	Output current detection period	0 to 10 s	0.1 s	0	0.0	Timp intarziere semnal detectie curent iesire
P152	Zero current detection level	0 to 200.0%	0.1%	5.0%	5.0	Prag detectie curent zero
P153	Zero current detection period	0.05 to 1 s	0.01 s	0.5 s	0.50	Temporizare detectie curent zero

Numar parametru	Semnificatie	Domeniu setare	Increment minim setare	Setarea din fabrica	Setarea adoptata in aplicatia curenta	Comentariu
P156	Stall prevention operation selection	0 to 31,100	1	0	0	Setare functie limitare curent (prevenire blocare motor)
P158	AM terminal function selection	0, 1, 2	1	0	0	Setare functie terminal AM

Numar parametru	Semnificatie	Domeniu setare	Increment minim setare	Setarea din fabrica	Setarea adoptata in aplicatia curenta	Comentariu
P160	User group read selection	0, 1, 10, 11	1	0	0	Setare acces grup utilizatori
P168	Parameter set by manufacturer. Do not set.				7471	Parametru setat de producator. Nu setati.
P169	Parameter set by manufacturer. Do not set.				2	Parametru setat de producator. Nu setati.

Numar parametru	Semnificatie	Domeniu setare	Increment minim setare	Setarea din fabrica	Setarea adoptata in aplicatia curenta	Comentariu
P171	Actual operation hour meter clear	0	-	0	0	Stergere contor ore functionare

Numar parametru	Semnificatie	Domeniu setare	Increment minim setare	Setarea din fabrica	Setarea adoptata in aplicatia curenta	Comentariu
P173	User group1 registration	0 to 999	1	0	0	Inregistrare grup1 utilizatori
P174	User group1 deletion	0 to 999,9999	1	0	0	Stergere grup1 utilizatori
P175	User group2 registration	0 to 999	1	0	0	Inregistrare grup2 utilizatori
P176	User group2 deletion	0 to 999,9999	1	0	0	Stergere grup2 utilizatori

Numar parametru	Semnificatie	Domeniu setare	Increment minim setare	Setarea din fabrica	Setarea adoptata in aplicatia curenta	Comentariu
P180					0
P181					1
P182					2
P183					6
P190					0
P191					4
P192					0

Numar parametru	Semnificatie	Domeniu setare	Increment minim setare	Setarea din fabrica	Setarea adoptata in aplicatia curenta	Comentariu
P232					9999Hz
P233					9999Hz
P234					9999Hz
P235					9999Hz
P236					9999Hz
P237					9999Hz
P238					9999Hz
P239					9999Hz

Numar parametru	Semnificatie	Domeniu setare	Increment minim setare	Setarea din fabrica	Setarea adoptata in aplicatia curenta	Comentariu
P240					1
P244					1
P245					9999
P246					0.50
P247					9999

Numar parametru	Semnificatie	Domeniu setare	Increment minim setare	Setarea din fabrica	Setarea adoptata in aplicatia curenta	Comentariu
P250					9999

Numar parametru	Semnificatie	Domeniu setare	Increment minim setare	Setarea din fabrica	Setarea adoptata in aplicatia curenta	Comentariu
P251	Output phase failure protection selection				1

Numar parametru	Semnificatie	Domeniu setare	Increment minim setare	Setarea din fabrica	Setarea adoptata in aplicatia curenta	Comentariu
P342	EEPROM write selection				0

Numar parametru	Semnificatie	Domeniu setare	Increment minim setare	Setarea din fabrica	Setarea adoptata in aplicatia curenta	Comentariu
P901	AM terminal calibration	-	-	-	0.00Hz
P902	Frequency setting voltage bias	0 to 10V			0.00Hz
P903	Frequency setting voltage gain	0 to 10V			50.00Hz
P904	Frequency setting current bias	0 to 20mA			0.00Hz
P905	Frequency setting current gain	0 to 20mA			50.00Hz
P922					0.00Hz
P923					50.00Hz
P990					1
P991					63
